Description
1x50mm2 Halogen Free RV-K unipolar cable
Kbiflex RV-K 0,6-1 KV UNE 21123
Electrolytic copper conductor, class V flexibility, cross-linked polyethylene (XLPE) insulation, PVC outer cover, black or green color
Applications :
- LV energy distribution indoors and outdoors and in all types of installations where flexibility is required.
- Very suitable for use in high amperage direct current installations. For the interconnection of batteries, inverters, etc.
Technical data
- Rated voltage: 0.6-1 KV.
- Test voltage: 3500 V.
- Standard: UNE 21123-91/1 IEC 502
- Bending radius: 10 x diameter
- Service temperature: -20ºC. at +90ºC.
- Flame retardant: UNE 20432-1 IEC 332-1
- Fire non-spreader: IEEE 383-74
Contact us to receive more information.
